Engine & Transmission
Displacement313 ccCylinders1Max Power33 bhp @ 9,500 rpm
Maximum Torque28 @ 7,500 rpm
Bore80 mm
Stroke62.1 mm
Valves Per Cylinder4
Front Brake TypeDisc
Front Brake Size300 mm
Rear Brake TypeDisc
Rear Brake Size240 mm
Calliper TypeFront-4 Piston, Rear-Single Piston
Front Wheel Size17 inch
Rear Wheel Size17 inch
Front Tyre Size110/70 R 17
Rear Tyre Size150/60 R 17
Tyre TypeTubeless
Radial TyresYes
Wheel TypeAlloy
Front SuspensionUpside down fork , Ø 41 mm
Rear SuspensionSolid die-cast aluminum swingar
Fuel Delivery SystemElectronic Fuel Injection
Fuel TypePetrol
G 310 R Dimensions & ChassisDimensions & Chassis
Kerb Weight158.5 kg
Overall Length2,005 mm
Overall Width820 mm
Overall Height1,080 mm
Wheelbase1,380 mm
Ground Clearance--
Seat Height785 mm
Chassis TypeBolted steel frame, drive unit lo
Spark Plugs--
Cooling SystemWater Cooled
Gearbox TypeManual
No. of Gears6
Transmission TypeChain Drive
ClutchWet Multiple Disc
Fuel Tank Capacity11 litres
Reserve Fuel Capacity1 litres
Top Speed143 Kmph
Features
OdometerDigital
SpeedometerDigital
Fuel GuageYes
TachometerDigital
Pillion FootrestYes
Digital Fuel GuageYes
Start TypeElectric Start
Stand AlarmYes
No. of Tripmeters2
Tripmeter TypeDigital
Low Fuel IndicatorYes
Low Oil IndicatorYes
Low Battery IndicatorYes
Pillion GrabrailYes
Pillion SeatYes
Antilock Braking SystemYes
KillswitchYes
ClockYes
Battery12 V / 8 Ah, maintenance free
Brake/Tail LightLED
Turn SignalYes
Pass LightYes
