Specifications
Engine Type Four-Stroke, Single Cylinder, Water Cooled, Electric Start 4 Valve
Displacement 249.6mlml (250cc)
Bore x Stroke 77 x 53.6mm
Compression Ratio 11.5:1
Max Power 22.5kw / 9000rpm (1 � 5%) (30.15HP)
Ignition CDI
Transmission 5-Speed, International Shift Pattern, 1-N-2-3-4-5
Transmission Chain Drive Guard Ratio Front sprocket: 520-13T
Rear sprocket: 520-51T
Frame Twin spar Perimeter
Carburetor DELLORTO 34mm (MADE IN ITALY)
Suspension / Brakes / Tyres
Suspension Front Hydraulic, Fully Adjustable Forks 910mm / 35.82in 53mm Upper and 59mm Lower Diameter
Suspension Rear Hydraulic piggy back reservoir, Fully Adjustable Shock 500mm / 19.68in
Brakes Front Hydraulic 240mm Single Disc with Single Piston Calliper
Brakes Rear Hydraulic 230mm Single Disc with Dual Piston Calliper
Rim / Tyre Front 21′ 80/100-21 Aluminium/magnesium Alloy 7116
Rim / Tyre Rear 18′ 110/100-18 Aluminium/magnesium Alloy 7116
Dimensions
Length 2120mm / 83.46in.
Width 820mm / 32.28in.
Height 1245mm / 48.82in.
Wheelbase 1440mm / 59.69in.
Ground Clearance 320mm / 15.60in.
Seat Height 920mm / 36.22in.
Dry Weight 115kgs /238.7lbs.
Fuel Capacity 6.7L / 1.46 gal.
